The Comrod AV6K is a rugged, high-quality dipole antenna engineered for professional marine VHF radio telephone service . Trusted by military, law enforcement, and commercial vessels worldwide, this antenna delivers exceptional durability and reliable performance in the harshest maritime environments .
Key Features
Superior Construction
-
Centered coaxial dipole design with radiating elements completely enclosed in polyurethane foam within a rugged fiberglass tube
-
Hot dip galvanized mounting hardware for maximum corrosion resistance
-
Polyurethane lacquer finish (white) that withstands salt spray and UV exposure
-
Foam-filled construction that prevents condensation and corrosion of internal copper and brass elements—a Comrod exclusive
Technical Specifications
| Specification | Detail |
|---|---|
| Frequency Range | 156-162 MHz (VSWR <1.5:1) / 153-170 MHz (VSWR <2:1) |
| Gain | 2 dBi |
| Impedance | 50 ohms |
| Power Rating | 200 W |
| Polarization | Vertical |
| Radiation Pattern | Omnidirectional in horizontal plane |
| Height | 1.4 m (4.6 ft) |
| Weight | 1.3 kg (without clamps) / 2.2 kg (with clamps) |
| Connector | N female standard; UHF female available |
| DC Grounded | Yes |
| Wind Rating | 55 m/s (125 mph / 201 km/h) |
| Temperature Range | -55°C to +55°C |
| Waterproofing | IP67 rated |
Benefits
The AV6K features Comrod’s innovative “no-twist” cable design with a swiveling BNC connection at the base. This allows the antenna to be threaded onto its mount without twisting the coaxial cable—a significant advantage when installing longer cable runs. Unlike competitors with pre-attached 20-foot cables, the AV6K accepts custom cable lengths, eliminating signal loss from splices .
Mounting & Compatibility
-
Designed for mast or post mounting with included ATC clamps
-
Connector protected by a plastic tube with stuffing nut
-
Suitable cable: RG8, RG213, or RG-8X (recommended for lowest loss)
