The CPU INDUSTRIAL DISPLAY EP4043C is a compact and efficient 4.3-inch Human-Machine Interface (HMI), designed for seamless integration into demanding industrial environments. Engineered for reliable operation, this display offers a powerful combination of performance and low power consumption, making it an ideal solution for factory automation, process control, and equipment monitoring.
Key Features & Benefits
- High-Performance Processing: Powered by a 600MHz ARM Cortex-A8 CPU, ensuring fast and responsive operation for your HMI applications .
- Vibrant 4.3″ Display: Features a 4.3-inch TFT LCD screen with a clear 480×272 resolution and 24-bit color depth, providing a sharp and colorful interface for operators .
- Ultra-Low Power Consumption: Operating at DC 24V and consuming only 3W (typical <5W) , this display is an energy-efficient choice for your industrial systems .
- Industrial-Grade Durability: The front panel is rated to IP65 protection standards, making it resistant to dust and water jets, ensuring reliable operation in harsh factory floor conditions .
- Robust Touchscreen: Equipped with a 4-wire industrial resistive touchscreen with a surface hardness of 4H, it is designed to withstand repeated use in industrial settings .
- Multiple Connectivity Options: Includes COM1 (RS232/RS485/RS422) and COM3 (RS232) ports for flexible communication with PLCs and other serial devices. It also features a USB Host port for connecting peripherals like a mouse or keyboard and a USB Device port for fast program downloads .
- Designed for Harsh Environments: The motherboard is coated with a three-proof coating to protect against dust, moisture, and corrosion, ensuring long-term stability. It also features high EMC protection, withstanding lightning surges and burst transients up to ±4KV .
- Easy Installation: Features a compact design with a mounting cutout of 120mm x 93mm, allowing for simple panel mounting in new or existing equipment .
Technical Specifications
| Feature | Specification |
|---|---|
| Manufacturer | CPU / COOL-TEX |
| Model | EP4043C |
| Part Number | EP4043C2018030007 |
| Display Size | 4.3″ TFT LCD |
| Resolution | 480 x 272 pixels |
| Color Depth | 24-bit |
| Brightness | 300 cd/m² |
| CPU | 600MHz ARM Cortex-A8 |
| Memory | 128M Flash, 128M DDR3 |
| Touchscreen | 4-Wire Resistive, Hardness 4H |
| Input Voltage | DC 24V (Working Range DC 9V ~ 32V) |
| Power Consumption | < 5W (Typical 3W) |
| Communication Ports | COM1: RS232/RS485/RS422; COM3: RS232 |
| USB Ports | 1x USB Host 2.0, 1x USB Device 2.0 |
| Front Panel Rating | IP65 (when properly mounted) |
| Operating Temp. | 0°C to 50°C |
| Storage Temp. | -20°C to 60°C |
| Dimensions (WxHxD) | 128mm x 102mm x 32mm (without power terminal) |
| Cutout Dimensions | 120mm x 93mm |
| Weight | Approx. 500g |
| Certifications | CE, RoHS |
