The Consilium Marine SAL SD1-1 (SN 502-015) and SD2-5 (701492B) are high-performance marine display units designed to provide critical navigation data with exceptional clarity and reliability. As part of Consilium’s renowned SAL series, these displays are engineered to integrate seamlessly with Speed Logs (STW/SOG) and Echo Sounders, offering vessels a robust solution for monitoring speed through water, speed over ground, and accurate depth measurements.
Ideal for commercial shipping, tankers, passenger vessels, and offshore support ships, these displays ensure compliance with IMO and SOLAS regulations by delivering real-time data essential for safe maneuvering, docking, and navigation in congested or shallow waters .
Key Features & Benefits
-
Versatile Dual Functionality: Designed to operate as a dedicated Speed Log Master Display or as an Echo Sounder repeater, providing critical “Speed through Water” (STW), “Speed over Ground” (SOG), and depth data in a single unit .
-
Seamless System Integration: Fully compatible with the Consilium SAL R1a, SAL R1E, and SAL T3 series. Communicates via standard NMEA 0183 / IEC 61162-1 protocols, allowing easy connection to ECDIS, Radar, Autopilot, and Voyage Data Recorders (VDR) .
-
Rugged Marine Construction: Built to withstand harsh maritime environments, featuring durable casing resistant to vibration, moisture, and extreme temperatures (-15°C to +55°C) .
-
User-Friendly Interface: Equipped with clear digital readouts, dimmable backlighting for night navigation, and intuitive controls for remote calibration and setup of the speed log system from the bridge .
-
Type Approved: Meets the rigorous performance standards of IMO and IEC for Speed and Distance Measuring Equipment (SDME) and Echo Sounders .
Technical Specifications
| Specification | Detail |
|---|---|
| Model Numbers | SAL SD1-1 |
| Primary Function | Speed Display & Depth Display |
| Compatibility | Consilium SAL R1a, R1E, T2+, T3, E1, E2 Systems |
| Data Protocol | NMEA 0183 / IEC 61162-1 |
| Speed Range (Log) | 0 to 40 knots (SOG) / ±50 knots (STW sensed) |
| Speed Accuracy | ±0.1 knots or 0.5% of reading (whichever is greater) |
| Depth Range (Sounder) | Up to 1000m (dependent on transducer frequency: 50/200 kHz) |
| Power Supply | 24 V DC (typically supplied by ELC Electronics Cabinet) |
| Operating Temp | -15°C to +55°C |
Applications
-
Bridge Navigation: Mounted on the bridge console or wings to provide officers with immediate visual confirmation of vessel speed and under-keel clearance.
-
Docking & Maneuvering: Provides precise low-speed readings (ahead/astern) critical for docking in tight harbors .
-
System Retrofits: Ideal for replacing older analog displays (e.g., SD4 series) while maintaining compatibility with existing Consilium hull transducers and electronics
