- BRAND: TELEMECANIQUE
- MODEL: XCM-F102
- NFC 63-140
- 300V- 6A
- IEC 337-1
- VDE 0660 TEIL 2
- XCM – NFC
- 63140
- 300V, 6A
- MADE IN USA
Telemecanique XCM-F102 NFC 63-140 – Complete Product Description
The Telemecanique XCM-F102 NFC 63-140 is a compact, DIN-rail mounted rotary handle control switch designed for manual control and isolation of electrical circuits. It is part of the renowned Telemecanique (now Schneider Electric) XCM series, known for its reliability and safety in industrial applications.
The markings on the device provide key information about its certifications and electrical ratings, making it suitable for a wide range of industrial and control panel applications.
Key Features
-
Compact Design:Â Saves space in control panels with its slim profile.
-
Rotary Handle Operation:Â Provides clear, positive switching action with a robust handle.
-
DIN-Rail Mounting:Â Easy and quick installation on standard TS35 DIN rails.
-
High Switching Capacity:Â Rated for 6A at 300V, making it suitable for controlling motors, solenoids, and other inductive loads.
-
Safety Certifications:Â Complies with key international safety standards, including the German VDE 0660 standard.
-
Clear Contact Position Indication:Â The handle mechanism provides a clear visual indication of the switch status (On/Off).
-
Snap-on Mounting:Â Accessory contact blocks and terminals can be easily snapped onto the base unit.
Detailed Breakdown of the Markings
-
TELEMECANIQUE: The original manufacturer, now a flagship brand under Schneider Electric.
-
XCM:Â The series name for this family of control and isolation switches.
-
NFC 63-140:Â This is the specific French (UTE) standard that the switch complies with, relating to low-voltage switchgear and controlgear.
-
300V 6A: The electrical rating. The switch is rated for a maximum of 6 Amperes at a voltage of up to 300 Volts.
-
VDE 0660: This is a crucial German safety standard from the VDE (Verband der Elektrotechnik, Elektronik und Informationstechnik) for circuit-breakers, switches, and similar equipment. This certification confirms the device has been tested and approved for safety and performance in the German market, which is highly respected worldwide.
-
TELI2 TEIL 2: This marking refers to a specific part of the German TEL (Technische Lieferbedingungen – Technical Delivery Conditions) standard, likely related to the quality, testing, and delivery specifications for control circuit devices.
-
XCM-F102: This is the specific commercial reference or order code for this exact model. It identifies a base unit with a specific actuator and configuration.
Technical Specifications (Typical for XCM-F102)
| Feature | Specification |
|---|---|
| Product Type | Rotary Control Switch |
| Series | Telemecanique XCM |
| Rated Operational Current (Ie) | 6 A |
| Rated Operational Voltage (Ue) | 300 V |
| Rated Insulation Voltage (Ui) | 690 V |
| Utilization Category | AC-15 (Switching of control circuits electromagnetic loads >72 VA) |
| Mechanical Life | Typically > 1,000,000 cycles |
| Electrical Life | Typically > 100,000 cycles (at rated load) |
| Mounting | Standard 35 mm DIN Rail (TS35) |
| Terminal Type | Cage-clamp or screw-clamp (depending on specific version) |
| Standards & Certifications | VDE 0660, NFC 63-140, IEC/EN 60947-1, IEC/EN 60947-5-1 |
| Contact Configuration (Base) | 2 positions (ON-OFF) |
Typical Applications
This switch is designed for manual control in industrial environments. Common applications include:
-
Machine Control Stations:Â As a main On/Off switch or a mode selector.
-
Control Panel Isolation:Â To safely isolate a section of a control circuit for maintenance.
-
Motor Control Circuits:Â For starting and stopping small motors.
-
Automation Systems:Â As a manual override or control input.
