TELEMECANIQUE XCK-M POSITION SWITCH LIMIT SWITCH XCKM EN 60 947 5.1 ROLLER ZCK D21 12:13

• BRAND: TELEMECANIQUE
• MODEL: XCK-M
• POSITION SWITCH
• LIMIT SWITCH
• Ui: 500V
• EN 60 947.5.1
• Uimp: 6KV
• AC15, 240V, 3A
• IP66
• 10(4)A.400V
• ZCK-D21
• MADE IN FRANCE

The Telemecanique XCK-M is a robust and versatile mechanical limit switch designed for precise position detection and control in industrial automation applications. Known for its reliability and durability, this switch is part of the renowned Telemecanique (now Schneider Electric) XCK family, built to meet international standards for performance and safety.

Key Features & Specifications

• Product Type: Mechanical Limit Switch / Position Switch

• Manufacturer Brand: Telemecanique (Schneider Electric)

• Model: XCK-M

• Actuator Type: Roller Lever (ZCK D21)

  • The “ZCK D21” denotes a specific roller lever actuator type, which is ideal for sensing the position of cams, machine parts, or products from a side-to-side motion.

• Standard: EN 60947-5-1

  • This is the European standard for control circuit devices and switching elements, guaranteeing its compliance with strict safety and performance requirements.

• Contact Configuration: Typically 1 NO + 1 NC (Normally Open + Normally Closed). Specific contact blocks can vary.

• Electrical Rating: Designed for control circuits. Common ratings are up to 600V and 10A, but the exact rating depends on the specific contact block used.

• Housing: Robust metal or high-grade plastic enclosure, offering a high degree of protection, commonly IP65 or higher.

  • IP65 Rating: “Dust-tight” and protected against water jets from any direction, making it suitable for harsh industrial environments with dust, chips, and coolants.

• Mechanical Life: Extremely high, often in the millions of cycles, due to its robust construction.

• Termination: Screw terminals for secure and reliable wiring.

Applications & Common Uses

The XCK-M limit switch is used across various industries to detect the presence or position of a machine part and send a control signal to a PLC, relay, or motor starter.

• Machine Tooling: Detecting the end of travel for slides, turrets, and tool changers.

• Material Handling: Position sensing on conveyor systems, automated storage and retrieval systems (AS/RS), and palletizers.

• Packaging Machinery: Verifying the position of cams, arms, and filling heads.

• Automated Assembly Lines: Ensuring components are in the correct position before a process begins.

• Door & Gate Control: Interlocking and position feedback for industrial doors, guards, and elevators.

Why Choose the Telemecanique XCK-M?

• Proven Reliability: A classic, industry-standard component known for long service life.

• Durability: Built to withstand mechanical shock, vibration, and harsh environmental conditions.

• Safety Compliance: Conforms to EN 60947-5-1, ensuring safe operation in control circuits.

• Versatility: Available with various actuator types (like the roller lever ZCK D21) and contact blocks to suit a wide range of applications.

• Global Brand Support: As a Schneider Electric product, it is supported by a global supply chain and technical resources.
