SCHNEIDER ELECTRIC TSX-LES70 / TSXLES70 JUNCTION FOR TRANS. MOD NEW BOX NOT AVAILABLE FRANCE 16:19

The TSX-LES70 is a junction module (or terminal block) designed specifically for use with Schneider Electric’s TSX 07 series of transmitter modules for their Modicon Premium programmable logic controllers (PLCs).

Its primary function is to provide a convenient and organized connection point between the field wiring (sensors, actuators) and the more complex transmitter or acquisition modules in the rack. It acts as an extension of the module’s terminals, making installation and maintenance easier.

Key Identifiers from Your Text:

• Model: TSX-LES70 (often written as TSX LES70)

• Condition: New (as per your listing)

• Origin: Manufactured in France.

• Packaging: Original box is not available.

Detailed Product Description

1. Function:
The TSX-LES70 is a passive junction interface. It doesn’t perform any signal processing or logic functions. Instead, it serves as a wiring hub, allowing you to connect field devices to the PLC system neatly. It is specifically designed to pair with transmitter modules, which are used for connecting analog signals (like 4-20mA, 0-10V) or specific digital sensors.

2. Physical Characteristics:

• Type: A rigid plastic block with multiple screw terminals.

• Mounting: It is designed to snap directly onto a standard DIN rail within a control panel.

• Connections: The module features a plug on its rear that connects directly to the mating transmitter module (e.g., a TSX-ASX—– module) when mounted side-by-side. The front or top side contains the screw terminals for the field wiring.

3. Compatibility:
This junction module is part of the Modicon Premium PLC system (TSX P57 / TSX PPC – – -). It is exclusively compatible with the “Transmitter Module” form factor of the TSX 07 series I/O. You must verify that you have a transmitter module that requires this specific type of junction block.

4. Typical Use Case:
In an automation panel, the sequence from the field to the PLC CPU would be:
Field Sensor (e.g., a 4-20mA pressure transmitter) -> Field wires connected to terminals on the TSX-LES70 -> The LES70 plugs directly into the back of a TSX Transmitter Module (e.g., TSX-ASX—–) -> The transmitter module is plugged into the Modicon Premium rack -> The rack communicates with the PLC CPU.

5. SEO-Optimized Summary for a Listing:

Schneider Electric TSX-LES70 Junction Module for Transmitter Modules

This is a new, genuine Schneider Electric TSX LES70 junction terminal block. It is designed in France for the Modicon Premium (TSX P57 series) automation platform.

Key Features:

• Use: Junction interface for TSX 07 series transmitter I/O modules.

• Function: Provides screw terminals for easy field wiring connection to analog/digital transmitter modules.

• Condition: Brand new and unused. (Note: Original box is not included).

• Compatibility: Essential spare part for Premium PLC systems. Must be used with compatible transmitter modules like the TSX-ASX—- series.

Ideal for panel builders, maintenance engineers, and system integrators working with Schneider Electric Modicon Premium PLC systems.
