OMRON G7SA-3A1B 24VDC Relay with P7SA-10F-ND Socket Base 12:05

• NUMBER OF POLES:                                                               2 POLES
• MANUFACTURER:                                                                   OMRON AUTOMATION AND SAFETY
• SERIES:                                                                                    G7SA
• COIL VOLTAGE:                                                                        24 VDC
• CURRENT:                                                                                 6 A
• SWITCHING VOLTAGE:                                                            250 VAC
• COIL CURRENT:                                                                        15 mA
• TYPE:                                                                                         GENERAL PURPOSE RELAYS
• COUNTRY:                                                                                 CHINA

The Omron G7SA-3A1B is a compact, high-reliability safety relay designed for PCB (Printed Circuit Board) mounting, offering robust power switching in a space-saving package. When paired with the dedicated P7SA-10F-ND socket base, it creates a secure and easily serviceable connection, ideal for industrial control panels, automation systems, and safety circuits.

This relay features a Single-Pole, Single-Throw, Normally Open (SPST-NO or 1 Form A) contact configuration. It is rated for a substantial 10A load at 250VAC or 30VDC, making it capable of controlling motors, solenoids, heaters, and other demanding loads. The coil operates on 24VDC, a standard voltage in industrial environments.

The inclusion of the P7SA-10F-ND socket allows for quick wiring and easy replacement of the relay without soldering, significantly reducing maintenance time and effort. This combination is a trusted solution for applications requiring dependable circuit isolation and power control.

Key Features & Benefits

• High-Capacity Switching: Handles up to 10A for both AC (250V) and DC (30V) loads, providing versatile power control.

• Compact & Space-Saving: Slim design is perfect for high-density PCB layouts, saving valuable panel space.

• PCB Mount & Socket Compatible: The G7SA-3A1B relays mount directly to the board, while the P7SA-10F-ND socket enables tool-less installation and removal for easy maintenance.

• Secure Connection: The socket base ensures a reliable electrical and mechanical connection, preventing loose contacts.

• Clear Status Indication: Features a mechanical flag indicator to visually confirm the relay’s ON/OFF status at a glance.

• Safety-Oriented Design: Often used in circuits where reliable operation is critical for machine safety and interlocking.

• International Standards: Compliant with worldwide safety and quality standards (UL, CSA, TÜV).

Technical Specifications

Applications

This relay and socket combination is ideal for a wide range of industrial and commercial applications, including:

• Industrial Control Panels

• Programmable Logic Controller (PLC) Output Modules

• Automation Machinery

• Safety Interlock Circuits

• Power Supplies & UPS Systems

• HVAC Control Systems

• Packaging Equipment
