FURUNO SHIP FASCIMILE RECEIVER DFAX FAX-207 TESTED INPUT 12 VDC 2711 1040

FURUNO SHIP FASCIMILE RECEIVER DFAX FAX-207 TESTED INPUT 12 VDC 2711 1040

DEVICE: WEATHERFAX

BRAND: FURUNO

TYPE: FAX 207 DFAX ( Dual Function Facsmile Receiver / WeatherFax )

The FAX-207 Dual Function Facsimile (DFAX) Receiver provides high resolution charts and satellite images trans-mitted from facsimile stations throughout the world. It can be programmed to receive facsimile broadcasts automat-ically, providing hands-off operation.
The FAX-207 has a wide variety of functions, all con-tained in a rugged plastic case which is small enough to fit on almost any class of vessel. All keys respond immedi-ately to the operator’s command. Each time a keying sequence is correctly executed the unit emits a “beep” to confirm that it has received the operator’s command.

• Noise-free, carbon dust-free thermal printing head.
  • High resolution thermal paper provides crisp and clean pictures in four tones. Cloud analysis picture (FM band) presented clearly.
  • Programmed with all existing facsimile stations and frequencies. Free memory provides for storage of up to 230 user channels.
  • Fully automatic operation by built-in schedule timer. Storage for up to 30 programs provided.
  • Fully automatic selection of speed, IOC, phase alignment, and frequency.
  • Easy-to-understand menu-driven operation.
  • Optional NAV RCV Board provides for reception of NAVTEX messages.
  • AM mode available (AM broadcast can be heard.)
  • Connectable to personal computer to use FAX-207 as a PC printer. (Optional I/F board required.)

The FURUNO DFAX FAX-207 is a compact, reliable, and professionally-grade marine weather chart recorder. Designed for seamless integration on various vessels, its primary function is to automatically receive and print high-quality weather maps, sea state analyses, and satellite images broadcast from coastal stations worldwide.

This unit is a tested and verified piece of equipment, confirmed to be in good working order with an input voltage of 12 VDC, making it ideal for most recreational and commercial marine applications.

Key Features & Specifications

• Model: DFAX FAX-207

• Product Type: Marine Weather Facsimile Receiver/Recorder

• Power Supply: 12 VDC (Tested and Verified), suitable for direct connection to standard shipboard power systems.

• Part Number / Model Code: 2711 1040

• Display: Easy-to-read LCD screen for status and menu information.

• Printing Method: Thermal line printing, ensuring quiet operation and sharp, clear outputs.

• Paper: Uses standard 216mm (8.5-inch) wide thermal paper rolls.

• Reception Modes: Fully automatic reception of Weather FAX (WEFAX) and Navtex (optional) messages.

• Memory: Built-in memory for storing multiple station schedules and settings.

• Synchronization: Automatic phase and synchronization for a stable, distortion-free image.

• Construction: Robust marine-grade housing designed to withstand the harsh shipboard environment.

Primary Functions & Uses

The DFAX FAX-207 provides mariners with critical meteorological data directly on the bridge. Its main functions include:

1. Weather Chart Reception: Automatically tunes into HF radio frequencies to receive and print:

   • Surface Analysis Charts

   • Wave Height and Period Analysis

   • Sea Surface Temperature Maps

   • Satellite Cloud Imagery (Infrared & Visual)

   • Weather Forecast Charts (12h, 24h, 48h, 96h)

   • Ice and Sea State Reports

2. Scheduled Recording: Users can pre-program the receiver with transmission schedules from stations across the globe (e.g., USCG, NOAA, JMH Japan, etc.). The unit will automatically turn on, receive the broadcast, and turn off, providing a hands-off operation.

3. Manual Operation: Allows for manual tuning and immediate printing of any active weather fax transmission.

Technical Condition & SEO-Optimized Highlights

• TESTED & VERIFIED: This unit has been professionally tested and is confirmed to be in good working condition. It is ready for immediate installation and use.

• 12 VDC INPUT: Perfect for yachts, fishing vessels, workboats, and other marine craft with standard 12-volt electrical systems.

• FURUNO RELIABILITY: Backed by Furuno’s renowned reputation for building durable and dependable marine electronics.

• COMPLETE MARINE WEATHER SOLUTION: An essential tool for voyage planning and ensuring safety at sea by providing a broad overview of weather patterns.

• LEGACY WORKHORSE: A proven and robust piece of equipment, sought after for its simplicity and effectiveness. An excellent backup or primary weather information system.
