FAGOR MCS – 04H AC SERVO DRIVE 22- 03060047

Fagor MCS-04H AC Servo Drive (22-03060047) – Product Description

The Fagor MCS-04H is a compact, high-performance digital AC servo drive designed to control synchronous servomotors in a wide range of industrial automation applications. It is part of Fagor’s reliable and versatile servo drive family, known for its ease of use, robust performance, and seamless integration with Fagor’s CNC systems and other automation controllers.

Key Features

• High Performance: Features advanced control algorithms (PIV + Feedforward) for precise speed, torque, and position control, ensuring high dynamic response and excellent trajectory following.

• Compact Design (H Frame): The “H” designation indicates a compact form factor, saving valuable panel space.

• Wide Power Range: The MCS-04H model is designed to drive servomotors with a continuous current of 4.0 A RMS and a peak current of 12.0 A RMS.

• Multiple Control Modes: Supports various operating modes to suit different application needs:

  • Torque Control Mode

  • Speed Control Mode

  • Position Control Mode (via pulse/direction or CW/CCW signals)

• Integrated Safety Functions: Includes built-in safety features such as overcurrent, overvoltage, undervoltage, overspeed, and motor overtemperature protection to ensure safe and reliable operation.

• Easy Setup and Tuning: Utilizes Fagor’s proprietary programming software for easy parameter configuration, auto-tuning, and real-time monitoring of drive and motor status.

• Comprehensive I/O: Equipped with digital and analog inputs and outputs for connecting limit switches, probes, and other peripheral devices.

• Seamless Integration: Designed for optimal performance when paired with Fagor CNCs (e.g., 8055, 8070 series) and PLCs, but can also be used with other master controllers via analog or pulse train commands.

Technical Specifications

Typical Applications

The Fagor MCS-04H servo drive is ideal for applications requiring precise motion control, such as:

• CNC Machinery: Milling machines, lathes, grinders, routers.

• Packaging Machines: For accurate positioning and speed synchronization.

• Material Handling: Pick-and-place robots, conveyor systems.

• Textile Machinery.

• Automated Assembly Lines.

Important Notes for SEO and Product Identification

• SEO Product Description: This text is optimized for search engines with relevant keywords like “AC Servo Drive,” “Fagor,” “MCS-04H,” and “22-03060047.”

• “SEO PRODUCT DISCRIPTION” in Query: The original query likely contained a typo (“DISCRIPTION” instead of “DESCRIPTION”). This description uses the correct spelling for better searchability.

• Compatibility: This drive is typically sold and used as part of a system with a matching Fagor Servomotor. When replacing a drive, it is crucial to ensure compatibility with the existing motor’s power and feedback type.

• Obsolete Status: It is important to note that the Fagor MCS series is considered a legacy or obsolete product line. While still found in many operating machines, Fagor has since released newer series like the Fagor AR (Advanced Rotary) and AL (Advanced Linear) servo drives, which offer enhanced features and performance.

Conclusion

The Fagor MCS-04H (22-03060047) is a robust and dependable servo drive from a reputable manufacturer in the industrial automation sector. It represents a solid generation of servo technology that has been widely used for years. For existing machinery maintenance, finding this drive or its equivalent replacement is key. For new designs, considering Fagor’s current-generation products is recommended.
