Description

AXIS Q7404 Features

• Resolution: NTSC: 720×480 to 176×120; PAL: 720×576 to 176×144
• Compression Styles: H.264 (MPEG-4 Part 10/AVC) Motion JPEG
• Frame Rate: 30/25 (NTSC/PAL) fps in all resolutions
• Image Settings: Compression, color, brightness, contrast, Rotation: 90°, 180°, 270°, Aspect ratio correction, Mirroring of images, Text and image overlay, Privacy mask, Enhanced deinterlace filter, Intelligent video, external inputs, video loss, disk full, File upload via FTP, HTTP and email, Notification via email, HTTP and TCP, External output activation, PTZ presets, Local storage
• Privacy Mask: Yes
• Built-in Microphone: No
• Audio Capabilities: Two way, full duplex, External microphone input or line input, Line level output
• Alarm/Event Management: Video motion detection, active tampering alarm, audio detection, Support for AXIS Camera Application Platform enabling installation of additional applications
• ONVIF: Yes
• Security: Password protection, IP address filtering, HTTPS encryption, IEEE 802.1X network access control, digest authentication, user access log
• Users: N/A
• On-board Storage: SD/SDHC memory card slot (Card is not included)
• Indoor/Outdoor: Indoor
• Housing/Enclosure Rating: N/A
• Dimensions: 194.4 mm (L) x 151 mm (W) x 35 mm (H) (7.6″ x 5.9″ x 1.4″)
• Weight: 796 g (1.75 lb.)
• Operating Temperature: 0 °C – 50 °C (32 °F – 122 °F)
• Operating Humidity: 20-80% RH (non-condensing)
• Power: 8-20 V DC, max. 7.2 W or Power over Ethernet IEEE 802.3af Class 2/3
