ABB SACE PR010/T LOW VOLTAGE CIRCUIT BREAKERS E1-E6 PROTECTION TESTER #1

ABB SACE PR010/T LOW VOLTAGE CIRCUIT BREAKERS E1-E6 PROTECTION TESTER #1

Ensure the absolute reliability and safety of your low voltage electrical systems with the ABB SACE PR010T Protection Tester. This professional-grade, portable unit is the definitive solution for testing, commissioning, and maintaining the entire range of ABB SACE Emax low voltage air circuit breakers, from series E1 to E6. Engineered for precision and ease of use in the field, the PR010T is an indispensable tool for electrical engineers, technicians, and service professionals.

Maximize System Uptime and Safety
Verify that your critical circuit breakers will operate exactly as designed during a fault condition. The PR010T performs comprehensive functional tests on all protection releases (PR1/P, PR2/P, PR3/V), ensuring compliance with safety standards and protecting your personnel and equipment from electrical hazards.

Key Features & Benefits

• Full-Range Compatibility: Seamlessly test all ABB SACE Emax low voltage circuit breakers (E1, E2, E3, E4, E5, E6) equipped with electronic trips. A single tester for your entire fleet streamlines inventory and training.

• Complete Protection Testing: Perform accurate and reliable tests on all protection functions:

  • Overcurrent (L, S, I): Long-time, Short-time, and Instantaneous tripping.

  • Ground Fault (G): Verify sensitive earth leakage protection.

  • Advanced Functions: Test custom protection curves, pre-alarms, and load monitoring.

• High-Power Current Injection: Generates high, stable output currents (up to 1000A) directly to the breaker’s current transformers, simulating real-world fault conditions without the need for bulky, external power sources.

• Intuitive, User-Friendly Operation: The clear control panel with a graphical display guides the user step-by-step through test setup and execution. Pre-loaded test routines and the ability to save custom test plans drastically reduce testing time and minimize human error.

• Direct Connection & Portability: The compact, robust design and dedicated connection cables allow for quick setup directly on the circuit breaker. Its portability makes it ideal for use in switchrooms, manufacturing plants, data centers, and other on-site locations.

• Detailed Reporting & Documentation: Generate professional test reports directly from the device. This provides verifiable proof of compliance, maintenance history, and breaker condition for audits and preventative maintenance schedules.

Technical Specifications

• Application: SACE Emax E1, E2, E3, E4, E5, E6 Circuit Breakers.

• Compatible Releases: PR1/P, PR2/P, PR3/V.

• Output Current: High-power output capable of injecting the currents required for testing all protection functions.

• Power Supply: Mains powered for reliable, high-current testing.

• Display: Graphical LCD for clear visualization of test parameters and results.

• Data Management: Internal memory for saving test configurations and results.

• Included Accessories: Typically includes a set of test leads, power cable, and protective carry case.
