ALLEN-BRADLEY 1734-AENTR I/O DUAL PORT NETWORK WITH ADAPTOR MODULE 1734 REV A01 17:06

The Allen-Bradley 1734-AENTR is a highly versatile, compact EtherNet/IP Network Adaptor module designed for the POINT I/O system. It serves as the communication gateway, connecting a bank of POINT I/O modules to a standard Ethernet network. The “Dual-Port” feature provides integrated network switch functionality, allowing for linear (daisy-chain) network topologies without the need for external switches. This module is a cornerstone for building distributed, modular I/O solutions in industrial automation applications.

Key Features & Benefits

1. Dual-Port Ethernet Switch:

   • Benefit: Enables daisy-chaining of multiple devices, reducing network infrastructure costs, cabling, and panel space by eliminating the need for external Ethernet switches at each node.

2. EtherNet/IP Communication:

   • Benefit: Seamlessly integrates into Allen-Bradley’s integrated architecture system using a standard, open network protocol. Allows for data exchange, configuration, and diagnostics with programmable controllers like CompactLogix and ControlLogix.

3. POINTBus Expansion:

   • Benefit: The module connects to the right-hand side to form a POINTBus, allowing you to add up to 16 (8 recommended for high-density modules due to power budget) various digital, analog, and specialty I/O modules in any combination to a single adaptor.

4. Compact Form Factor:

   • Benefit: The 1734 POINT I/O system is designed for high-density installations where panel space is limited. Each module is only 12mm wide.

5. Simple Integration with Rockwell Software:

   • Benefit: Uses a standard electronic data sheet (EDS) file for easy commissioning in RSLogix 5000 / Studio 5000 environments. The module supports explicit messaging for configuration and implicit (I/O) messaging for real-time data transfer.

6. Adapter Module Functionality:

   • Benefit: Operates as an Adapter in a EtherNet/IP scanner/adapter model. This means it listens for commands from a master controller (e.g., a CompactLogix processor) and manages the I/O data for all the modules on its local POINTBus.

7. Robust Design:

   • Benefit: Built for industrial environments with an operating temperature range of -20°C to 60°C (-4°F to 140°F) and certified for use in Class I, Division 2 hazardous locations.

Technical Specifications
